The Chengdu J-20 uses canards located at the front of its main wings. This configuration is quite rare on stealth aircraft. The Chengdu J-20’s canards improve the maneuverability of the Chengdu J-20 by providing additional lift at the front, which allows for better response to controls, especially at low speeds or high angles of attack. This configuration reduces the load on the main wing and offers increased aerodynamic efficiency during tight maneuvers.

The canards also create a vortex directed towards the wing, delaying stall and increasing turn control. This aerodynamic feature of the Chengdu J-20 allows for high performance in close air combat, unlike a pure delta wing.

The Chengdu J-20's canards: controlled agility or sacrificed stealth?

Increased maneuverability: a clear tactical advantage

Thanks to the canards, the maneuverability of the Chengdu J-20 excels in terms of agility. Pilots benefit from better pitch response, the ability to maintain control at high angles of attack, and faster initial rotation during takeoff. For example, the forward lift generated allows for a higher angle of attack without loss of lift, making complex maneuvers easier.

This design also incorporates thrust vectoring, further enhancing the aircraft’s dynamic capabilities. The result is a notable air combat effectiveness of the Chengdu J-20 with canards, suited to the demands of a modern adversary.

The compromise between maneuverability and stealth: a delicate balance

The canards involve a trade-off between maneuverability and stealth for the Chengdu J-20. Their presence increases the frontal radar signature, as these exposed surfaces can reflect waves. According to some analyses, this addition compromises the stealth of the Chengdu J-20, particularly when compared to designs without canards such as the F-22 or F-35. Critics point out that canards “guarantee radar detection.”

However, other studies estimate that their impact remains relatively minor on the overall RCS. Flight control software can temporarily minimize canard deflection during the most sensitive phases. In addition, a close delta-canard configuration limits aerodynamic disturbances and optimizes the compromise between maneuverability and stealth of the Chengdu J-20 as much as possible.

The context of the J-20’s technical choices

The designers deliberately opted for canards on the Chengdu J-20 as part of a strategic approach. Western aircraft favor full stealth, but the J-20 aims for a different profile, combining range, maneuverability, and penetration capabilities. Canards allow for superior tactical response, essential for interception or close combat in a dense environment.

The construction of the J-20 also incorporates other stealth technologies: DSI (divertless air intakes), composite surfaces, wave-absorbing coatings, internal air ducts, sawtooth doors, etc., seeking to mitigate the effect of the canards on the radar signature of the Chengdu J-20.

Comparison with other stealth fighters

While most fifth-generation fighters avoid canards to preserve stealth, a few American prototypes had considered them (JAST, X-36). Aircraft such as the Russian Su-57 use LEVCONs (wing-mounted aerodynamic control elements) instead, which are more discreet in terms of stealth. The J-20 opts for hybrid video, seeking a compromise between maneuverability and stealth for the Chengdu J-20, which remains unique in the stealth aircraft family.

The Chengdu J-20's canards: controlled agility or sacrificed stealth?

High-level performance

The impact of the canards is measurable in terms of agile response, high-angle control, and reduced loads on the main wing. These gains directly influence the J-20’s ability to engage quickly in contested areas. The canards on the Chengdu J-20 provide stability in tight maneuvers, while allowing for a lighter wing structure.

The limitations of the canard choice

However, this canard technology on the Chengdu J-20 imposes constraints. Radar surveillance of the canards, even when reduced, increases the complexity of stealth engineering. The surfaces must be perfectly aligned to avoid flush joints that could compromise the stealth of the Chengdu J-20. Finally, maintenance must ensure precise calibration of these moving surfaces, which increases logistical costs.

The Chengdu J-20 embodies a bold choice: to use canards for the maneuverability of the Chengdu J-20, while maintaining acceptable stealth through a combination of design, materials, and active control. It reflects a Chinese philosophy that values tactical agility as much as radar discretion.

This duel between agility and stealth is shaping the future of fighter jets. The J-20’s canards illustrate that the journey is not always linear: sometimes, to dominate the skies, you have to accept a few calculated compromises.
